Rele SPST-NO 6V max10A Panasonic

• High electrical noise immunity• High switching capacity in a compact housing• High sensitivity: 400mW• High surge voltage: 8.000V between Coil and contacts• High insulation min. 4mm between coil and contactALQ3_: SPST-NOContact Material: AgNiRated Current: 5AMax. Switching Current (N.O. / N.C.): 10A/3AMax. Switching Voltage: 250V ACRated Power ALQ3_: 200mWMax. Switching Power ALQ3_: 1.250VA/150W Min. Insulation Resistance.: 1.000MOhmMax. Operate/Release Time: 20/20msTesting Voltage Coil/Contact (1 min.): 4.000V ACOpen Contacts (1 min.) ALQ3_: 1000V ACMax. Operating Speed: 20 Operations/Min.Min. Lifetime, Mechanical: 10×106 OperationsOperating Temperature: -40…+85°CWeight Approx.: 7
